Product Description
(Formerly Sika WP Shield Primer)
DESCRIPTION
SikaShield Primer W-30 IN is single component, quick
drying, water based modified bituminous primer
which penetrates and activates the substrates. It improves
adhesion between the substrate and preformed
bituminous sheet membranes in SikaShield
range.
USES
Used as a primer for better adhesion of the torch-on
and stick-on Atactic Poly Propylene (APP) and Styrene
Butadiene Styrene (SBS) modified bituminous waterproofing
membranes.
CHARACTERISTICS / ADVANTAGES
Excellent bond with concrete, screed mor tar, porous
stones and lime-concrete substrates
Bonds well with old bituminous substrates
Easy application by brush, spray or roller
Good penetration in cementitious substrates
Effective activation of the surface to receive the waterproofing
sheet membrane
Specially designed for tropical conditions
PRODUCT INFORMATION
Chemical base Bitumen, water and additives
Packaging 20 kg metal drum
Shelf life 12 months from date of production
Storage conditions Store properly in original unopened, sealed and undamaged packaging, in
covered area at temperatures between +20 C and +35 C. Store vertically
with top side up. Protect from direct sunshine, rain, snow, ice, etc.
Appearance / Colour Pasty liquid / Black or brown
Density (1.00 0.05) g/mL (at +27 C) (IS 101 : Part 1 : Sec 7)
Solid content by weight (45 5) % (IS 101 : Part 2 : Sec 2)
APPLICATION INFORMATION
SikaShield Primer W-30 IN must be diluted with 20 % to 50 % clean water
to achieve the desired consistency.
NOTE
In case of exceptional site conditions, higher dilution can be done based on
Mixing ratio
1 / 3
site trials and advise of Sika Technical Service.
Consumption 0.2000.400 kg/m2 per coat (diluted)
NOTE
These figures are theoretical and does not consider any additional material
required due to surface porosity, surface profile, variations in level or
wastage etc.
Ambient air temperature +10 C min. / +40 C max.
Substrate temperature +10 C min. / +40 C max.
Substrate moisture content < 6 %
Test method: Sika-Tramex meter
Drying time Touch dry
(concrete substrate)
4 h max.
Hard dry
(concrete substrate)
6 h max.
(ASTM D1640)
The above values are at 23 2 C and 50 5 % relative humidity and may
vary according to the change in temperature, humidity, ventilation, wind,
substrate quality, etc.
BASIS OF PRODUCT DATA
All technical data stated in this Product Data Sheet are
based on laboratory tests. Actual measured data may
vary due to circumstances beyond our control.
ECOLOGY, HEALTH AND SAFETY
User must read the most recent corresponding Safety
Data Sheets (SDS) before using any products. The SDS
provides information and advice on the safe handling,
storage and disposal of chemical products and contains
physical, ecological, toxicological and other
safety-related data.
APPLICATION INSTRUCTIONS
Strictly follow installation procedures as defined in
method statements, application manuals and working
instructions which must always be adjusted to the actual
site conditions.
SUBSTRATE QUALITY
Concrete, lime-concrete and mor tar screed surfaces
must be clean, free from grease, oil & loosely adhering
particles.
New concrete should be cured for at least 28 days
and should have a pull off strength 1.5 N/mm2.
SUBSTRATE PREPARATION
Cementitious or mineral based substrates to be prepared
mechanically using wire brush, grinder, abrasive
blast cleaning or scarifying equipment to remove
cement laitance and to achieve an open textured
surface.
Loose friable material and weak concrete to be completely
removed and surface defects such as
blowholes and voids must be fully exposed.
Use Sikadur or SikaLatex or Sika MonoTop range
of repair materials for filling in potholes, voids or
cracks on the substrates.
The cementitious substrates to be carefully assessed
for moisture content, air entrapment, and surface
finish prior to any primer application.
MIXING
SikaShield Primer W-30 IN is mixed with clean water
up to maximum 50 % to achieve desired consistency.
Stir the contents well before application.
IMPORTANT
The primer may become high viscous due to change in
ambient conditions like temperature and humidity
that might affect the consistency and increase consumption
of the primer. Under such situation, a site
modification by further diluting the primer as per the
advice of the Sika Technical Service may be necessary
to achieve the desired application consistency. The dilution
is to be fixed on the basis of site trials but not to
exceed 50 % by weight of the primer.
APPLICATION
IMPORTANT
Do not apply SikaShield Primer W-30 IN when it is
raining or when rain is imminent.
IMPORTANT
Do not apply SikaShield Primer W-30 IN on substrates
with oil or grease contamination.
IMPORTANT
Do not apply SikaShield Primer W-30 IN on dry surface
in extreme hot weather. Surface must be cooled
by spray or mist of water before application.
IMPORTANT
Apply the membrane within 24 hours of primer application.
Product Data Sheet
SikaShield Primer W-30 IN
April 2022, Version 01.01
020725601000000025
2 / 3
Apply bituminous primer to a clean, smooth and dry
surface by brush, roller or spray in single coat as per
consumption given. Ensure full wetting and coverage
of the surface.
1.
In some cases, a second coat of primer may be necessary,
allow 24 hours between successive coats.
2.
Application of bituminous membranes must be done
soon after the primer is hard dry.
3.
CLEANING OF TOOLS
Clean all tools and application equipment with water
immediately after use. Hardened and/or cured material
can be removed mechanically or using thinner.
LOCAL RESTRICTIONS
Note that as a result of specific local regulations the
declared data and recommended uses for this product
may vary from country to country. Consult the local
Product Data Sheet for exact product data and uses.
LEGAL NOTES
The information, and, in particular, the recommendations
relating to the application and end-use of Sika
products, are given in good faith based on Sika's current
knowledge and experience of the products when
properly stored, handled and applied under normal
conditions in accordance with Sika's recommendations.
In practice, the differences in materials, substrates
and actual site conditions are such that no warranty
in respect of merchantability or of fitness for a
particular purpose, nor any liability arising out of any
legal relationship whatsoever, can be inferred either
from this information, or from any written recommendations,
or from any other advice offered. The
user of the product must test the products suitability
for the intended application and purpose. Sika reserves
the right to change the properties of its
products. The proprietary rights of third parties must
be observed. All orders are accepted subject to our
current terms of sale and delivery. Users must always
refer to the most recent issue of the local Product
Data Sheet for the product concerned, copies of which
will be supplied on request.
