Sika Grout 214 IN
370.0 INR/Bag
Product Details:
- Material Grade Mixed density : 2.15 kg/L
- Purity Dmax: 2.36 mm
- Form Mixing ratio Application Water to powder ratio Quantity of water per bag Flowable Water : Powder = 0.15 to 0.16 (by weight) 4.5 L to 4.8 L Pourable Water : Powder = 0.14 (by weight) 4.2 L
- Features Pull-out bond strength Time Pull out bond strength 7 days ~19 N/mm2 28 days ~20 N/mm2
- Usage Dual shrinkage compensated Suitable for temperature of above 0 C up to +200 C Easy to mix, only add water Adjustable consistency Very good flow characteristics Rapid strength development Excellent bond to concrete No segregation or bleeding High final strengths Initial expansion by gas generation Impact and vibration resistant Non-corrosive to anchor bolts, base plate / saddle / frame, sliding plate Not harmful to concrete and reinforcing steel Not flammable Non-toxic Frost, oil and fire resistant Require normal curing Suitable to use under restraints and grout thickness required Expansive to counteract initial shrinkage Maximum flow distance is compatible to the dimensions of base plate / saddle / frame Resistant to the chemicals, gases etc. being handled in equipment Chloride free
- Application To grout bearings, machine foundations, columns joints in precast construction etc. To grout anchors in concrete To grout cavities, gaps and voids in concrete To grout base plate of turbine, compressor, boilers, pumps and heavy machinery Sealing around penetrations Post fixing
- Installation Type The concrete must be structurally sound, thoroughly clean, free from oil, grease, dust, loose material, surface contamination and materials which will impair the grout flow or reduce adhesion strength. Laitance, delaminated, weak, damaged and deteriorated concrete and where necessary unsound concrete must be removed by suitable mechanical preparation as directed by the engineer or supervising officer. Any pockets or holes for structural fixings must also be cleaned of all debris.
- Click to View more
X
Sika Grout 214 IN Price And Quantity
- 1 Bag
- 370.0 INR/Bag
Sika Grout 214 IN Product Specifications
- Flexural strength Curing time Flexural strength 7 days ~9 N/mm2 28 days ~10 N/mm2
- Polished
- Splitting tensile strength ~3.5 N/mm2 (water : powder = 0.15, 28 days, +30 C)
- Mixed density : 2.15 kg/L
- Mixing ratio Application Water to powder ratio Quantity of water per bag Flowable Water : Powder = 0.15 to 0.16 (by weight) 4.5 L to 4.8 L Pourable Water : Powder = 0.14 (by weight) 4.2 L
- Dmax: 2.36 mm
- Pull-out bond strength Time Pull out bond strength 7 days ~19 N/mm2 28 days ~20 N/mm2
- Dual shrinkage compensated Suitable for temperature of above 0 C up to +200 C Easy to mix, only add water Adjustable consistency Very good flow characteristics Rapid strength development Excellent bond to concrete No segregation or bleeding High final strengths Initial expansion by gas generation Impact and vibration resistant Non-corrosive to anchor bolts, base plate / saddle / frame, sliding plate Not harmful to concrete and reinforcing steel Not flammable Non-toxic Frost, oil and fire resistant Require normal curing Suitable to use under restraints and grout thickness required Expansive to counteract initial shrinkage Maximum flow distance is compatible to the dimensions of base plate / saddle / frame Resistant to the chemicals, gases etc. being handled in equipment Chloride free
- BAG
- 30 Kg Bag
- To grout bearings, machine foundations, columns joints in precast construction etc. To grout anchors in concrete To grout cavities, gaps and voids in concrete To grout base plate of turbine, compressor, boilers, pumps and heavy machinery Sealing around penetrations Post fixing
- ASTM C1107
- The concrete must be structurally sound, thoroughly clean, free from oil, grease, dust, loose material, surface contamination and materials which will impair the grout flow or reduce adhesion strength. Laitance, delaminated, weak, damaged and deteriorated concrete and where necessary unsound concrete must be removed by suitable mechanical preparation as directed by the engineer or supervising officer. Any pockets or holes for structural fixings must also be cleaned of all debris.
- 30 Kilograms (kg)
Sika Grout 214 IN Trade Information
- KOLKATA
- Cash Advance (CA) Cash in Advance (CID)
- 200 Bag Per Day
- 2 Days
- No
- Contact us for information regarding our sample policy
- 30 Kg Bag
- Bihar Jharkhand Odisha East India West Bengal
- (EN ISO 2811-1)
Product Description
High strength non-shrink pourable cementitious precision grout
DESCRIPTION
SikaGrout-214 IN is a cement based 1-component,
ready to mix, non-shrink, pourable and flowable, two
stage expanding engineering grout in dry powder
form. It is widely used for precision grouting in engineering
applications subjected to static and dynamic
loads.
USES
To grout bearings, machine foundations, columns
joints in precast construction etc.
To grout anchors in concrete
To grout cavities, gaps and voids in concrete
To grout base plate of turbine, compressor, boilers,
pumps and heavy machinery
Sealing around penetrations
Post fixings
CHARACTERISTICS / ADVANTAGES
Dual shrinkage compensated
Suitable for temperature of above 0 C up to +200 C
Easy to mix, only add water
Adjustable consistency
Very good flow characteristics
Rapid strength development
Excellent bond to concrete
No segregation or bleeding
High final strengths
Initial expansion by gas generation
Impact and vibration resistant
Non-corrosive to anchor bolts, base plate / saddle /
frame, sliding plate
Not harmful to concrete and reinforcing steel
Not flammable
Non-toxic
Frost, oil and fire resistant
Require normal curing
Suitable to use under restraints and grout thickness
required
Expansive to counteract initial shrinkage
Maximum flow distance is compatible to the dimensions
of base plate / saddle / frame
Resistant to the chemicals, gases etc. being handled
in equipment
Chloride free
PRODUCT INFORMATION
Product declaration ASTM C1107
Chemical base Portland cement, special additives and aggregates
Packaging 30 kg bag
Shelf life 6 months from date of production
Storage conditions The product must be stored properly in undamaged and unopened original
sealed packaging in dry conditions at temperatures between +5 C and
+35 C. Protect from moisture, direct sunlight and frost.
1 / 4
Appearance / Colour Grey powder
Maximum grain size Dmax: 2.36 mm
Density Mixed density : 2.15 kg/L (EN ISO 2811-1)
TECHNICAL INFORMATION
Compressive strength Curing time Compressive strength
1 day ~25 N/mm2
3 days ~35 N/mm2
7 days ~45 N/mm2
28 days ~65 N/mm2
(ASTM C109)
Values at water : powder = 0.15, cube size 70.6 mm, curing temperature
+30 C
Dynamic load test:
Specimens of SikaGrout-214 IN remained undamaged and show no
change in compressive strength after subjecting to alternate stress fluctuation
of 5 N/mm2 and 25 N/mm2 at 500 cycles per minute for 2 million
cycles.
Modulus of elasticity in compression ~30 000 N/mm2 (ASTM C469)
Flexural strength Curing time Flexural strength
7 days ~9 N/mm2
28 days ~10 N/mm2
(ASTM C293)
Values at water : powder = 0.15, curing temperature +30 C
Splitting tensile strength ~3.5 N/mm2 (water : powder = 0.15, 28 days, +30 C) (ASTM C496)
Tensile adhesion strength ~2 N/mm2 (28 days, +30 C) (EN 1542)
Pull-out bond strength Time Pull out bond strength
7 days ~19 N/mm2
28 days ~20 N/mm2
(IS : 2770 Part 1)
Shrinkage No shrinkage after initial setting
Expansion Upto 4 % (ASTM C1090)
APPLICATION INFORMATION
Mixing ratio Application Water to powder ratio Quantity of water per
bag
Flowable Water : Powder = 0.15
to 0.16 (by weight)
4.5 L to 4.8 L
Pourable Water : Powder = 0.14
(by weight)
4.2 L
Fresh mor tar density 20002300 kg/m3
Consumption ~1950 kg/m3 (water : powder = 0.15)
Layer thickness 100 mm max.
Note: Higher layer thickness can be done with addition of aggregates. Contact
Sika Technical Services for additional information.
Ambient air temperature +5 C min. / +40 C max.
Substrate temperature +5 C min. / +40 C max.
Pot life ~20 minutes at +30 C (water : powder = 0.15)
Product Data Sheet
SikaGrout-214 IN
October 2023, Version 03.01
020201010010000327
2 / 4
BASIS OF PRODUCT DATA
All technical data stated in this Product Data Sheet are
based on laboratory tests. Actual measured data may
vary due to circumstances beyond our control.
FURTHER DOCUMENTS
Sika Method Statement : Cementitious grouting of machine
bases and base plates
ECOLOGY, HEALTH AND SAFETY
User must read the most recent corresponding Safety
Data Sheets (SDS) before using any products. The SDS
provides information and advice on the safe handling,
storage and disposal of chemical products and contains
physical, ecological, toxicological and other
safety-related data.
APPLICATION INSTRUCTIONS
SUBSTRATE QUALITY / PRE-TREATMENT
Concrete
The concrete must be structurally sound, thoroughly
clean, free from oil, grease, dust, loose material, surface
contamination and materials which will impair
the grout flow or reduce adhesion strength.
Laitance, delaminated, weak, damaged and deteriorated
concrete and where necessary unsound concrete
must be removed by suitable mechanical preparation
as directed by the engineer or supervising
officer.
Any pockets or holes for structural fixings must also
be cleaned of all debris.
Shutter Formwork
Where formwork is to be used, all formwork must be
of adequate strength, treated with release agent and
sealed to prevent leakage of pre-wetting water and
grout.
Ensure formwork includes outlets for removal of the
pre-soaking water or use vacuum extraction equipment
to remove water.
For manual grout application, a header box or hopper
must be constructed on one side of the formwork
so that a minimum grout head of 150200 mm
can be maintained during the grouting operation.
MIXING
IMPORTANT
Do not add more water than the maximum specified.
IMPORTANT
Do not use continuous mixing equipment.
IMPORTANT
For large bedding holes and higher gaps or based on
some specific customer requirements, duly washed
coarse aggregates of size 6 mm down may be mixed
with SikaGrout-214 IN in the proportion of grout : aggregate
= 2 : 1 (by weight). Trials are recommended to
confirm suitability of aggregates to be used.
Electric single or double paddle mixer
1. Pour around 80 to 90 % of recommended amount of
clean water into a clean mixing container.
2. Stir water slowly with a spiral paddle (< 500 rpm).
Add the complete bag of powder into the water
while stirring slowly.
3.
Add balance quantity of water and mix continuously
for 3 minutes to achieve a uniform and lump free
smooth consistency.
4.
Wait for 12 minutes to allow the entrapped air to
escape.
5.
Grout mixer
IMPORTANT
Product must be mixed using suitable grout mixing
equipment combined with agitator for large volume
mixing.
IMPORTANT
Volume capacity of equipment must be proportionally
greater than the volume of material being mixed.
Note: Equipment trials must be considered to make
sure product can be mixed satisfactory before full
project application.
Pour the minimum water ratio in the correct proportion
into the grout mixer.
1.
While stirring the water, slowly add the powder to
the water.
2.
Add more water within the mixing time up to the
maximum allowed until the required consistency is
achieved.
3.
Mix continuously for a minimum of 4 minutes. For
larger mixes the mixing time must be extended to
approximately 6 minutes or as necessary until the
grout achieves a lump free smooth consistency.
4.
APPLICATION
IMPORTANT
Do not use SikaGrout-214 IN for patch repair work or
overlay in unconfined spaces etc.
IMPORTANT
Avoid application in direct sun and/or strong wind.
IMPORTANT
Protect freshly applied material from freezing and
frost.
Strictly follow installation procedures as defined in
method statements, application manuals and working
instructions which must always be adjusted to the actual
site conditions.
Pre-wetting
The prepared concrete substrate must be thoroughly
saturated with clean water for a recommended minimum
2 hours before application of the grout.
The surface must not be allowed to dry within this
time.
Before application of the grout, all water must be removed
from within formwork, cavities or pockets
and the final surface must achieve a dark matt appearance
(saturated surface dry) without glistening.
Placing: Manual application
Apply the material within ~10 minutes after mixing
to take advantage of the expansion properties.
1.
Immediately after mixing, pour the mixed grout into
the header box or hopper ensuring continuous grout
2.
Product Data Sheet
SikaGrout-214 IN
October 2023, Version 03.01
020201010010000327
3 / 4
flow during the complete grouting operation to avoid
trapping air.
Placing: Grout pump application
For large volume placement, grout pumps are recommended.
Equipment trials must be considered to ensure
product can be pumped satisfactory.
Surface finishing
IMPORTANT
Do not add additional water on the surface.
IMPORTANT
Do not over work the surface as this may cause surface
discolouration and cra cking.
Finish exposed grout surfaces to the required surface
texture as soon as the grout has started to stiffen.
1.
After the grout has initially hardened, remove formwork
and trim edges while concrete is green.
2.
Cold weather working
Consider storing bags in a warm environment and using
warm water to assist with achieving strength gain
and maintaining physical properties.
Hot weather working
Consider storing bags in a cool environment and using
cold water to assist with controlling the exothermic
reaction to reduce crac king and maintaining
physical properties.
CURING TREATMENT
Protect exposed grout surfaces after finishing from
premature drying and crac king by curing under water
for at least 72 hours. Keep exposed surfaces to a
minimum.
In cold weather, apply insulated blankets to maintain
a constant temperature to prevent surface damage
from freezing and frost.
CLEANING OF TOOLS
Clean all tools and application equipment with water
immediately after use. Hardened material can only be
mechanically removed.
LOCAL RESTRICTIONS
Note that as a result of specific local regulations the
declared data and recommended uses for this product
may vary from country to country. Consult the local
Product Data Sheet for exact product data and uses.
LEGAL NOTES
The information, and, in particular, the recommendations
relating to the application and end-use of Sika
products, are given in good faith based on Sika's current
knowledge and experience of the products when
properly stored, handled and applied under normal
conditions in accordance with Sika's recommendations.
In practice, the differences in materials, substrates
and actual site conditions are such that no warranty
in respect of merchantability or of fitness for a
particular purpose, nor any liability arising out of any
legal relationship whatsoever, can be inferred either
from this information, or from any written recommendations,
or from any other advice offered. The
user of the product must test the products suitability
for the intended application and purpose. Sika reserves
the right to change the properties of its
products. The proprietary rights of third parties must
be observed. All orders are accepted subject to our
current terms of sale and delivery. Users must always
refer to the most recent issue of the local Product
Data Sheet for the product concerned, copies
Tell us about your requirement
Price:
Quantity
Select Unit
- 50
- 100
- 200
- 250
- 500
- 1000+
Additional detail
Mobile number
Email
Other Products in 'Ready to Mix' category
BRP ADHIKARY CHEMICALS PRIVATE LIMITED [142130][Kolkata](no images)
All Rights Reserved.(Terms of Use)
Developed and Managed by Infocom Network Private Limited.
Developed and Managed by Infocom Network Private Limited.
