Product Description
Sikalastic-520 Cool Coat Fibers IN is a 1-part, acrylic,
water based, elastic, cold applied liquid membrane
that can be applied directly from the container. It contains
addition of cross-linking polymers, special glass
micro fibres, pigments and advanced antifungal additive
that provides long lasting tough waterproofing
membrane. The high solar reflective index of the
membrane provides a heat reflective surface, minimises
surface temperature of the membrane and reduces
heat ingress keeping the interior of the building
cooler and thereby increasing thermal efficiency of the
building. The Product provides a seamless, smooth
waterproof finish which is resistant to UV exposure
and has elastic properties.
USES
Sikalastic-520 Cool Coat Fibers IN is used for:
Flat and sloping fully exposed roof structures
New construction and refurbishment projects
Waterproofing and renovation of old roof tiles
Waterproofing of external walls and sunshades
Roofs with numerous details such as penetrations,
drains, roof lights and complex geometry
Exterior coating for PVC water tanks
Sikalastic-520 Cool Coat Fibers IN is used on the following
substrates:
Concrete and cementitious substrates
Brick, masonry or renders
Unglazed clay tiles
Unglazed ceramic tiles
Asbestos or lime terraced roofs
CHARACTERISTICS / ADVANTAGES
High solar reflectance index (SRI)
Minimises the surface temperature on roof and walls
Reduces energy for cooling of buildings
High adhesion to concrete, render, masonry, corrugated
asbestos, bitumen, asbestos cement sheet and
metal decks
Crack-bridging
Highly flexible and vapour permeable
Low VOC content
Resistant to permanent UV exposure
Excellent weather resistance and good service life
High resistance to chloride penetration, hence highly
suitable for saline environment
Good resistance to mould and fungus
Cold applied - requires no heat or flame
Easy application by brush or roller
PRODUCT INFORMATION
Chemical base Acrylic polymer dispersion, micro fibres and antifungal additives
Packaging 10 kg container
Storage conditions The product must be stored properly in original, unopened and undamaged sealed packaging in dry conditions at temperatures between +5 C and +30 C. Appearance / Colour Thick viscous liquid / White or Grey Other colours on request subject to minimum order quantity. Important: Applied colours selected from colour charts will be approximate. Important: For colour matching, apply colour sample and confirm selected colour under real lighting conditions. Important: When product is exposed to direct sunlight, there may be some discolouration and colour variation, this has no influence on the function and performance of the product finish. Density ~1.35 kg/L (+30 C) Solid content by weight ~66 % TECHNICAL INFORMATION Shore A hardness ~45 (28d, +30 C) (ASTM D2240) Tensile strength ~1.5 N/mm2 (ASTM D412) Elongation at break 250 % (ASTM D412) Crack bridging ability Passes up to 3.2 mm (ASTM C1305) Tensile adhesion strength 1.5 N/mm2 (EN 1542) Tear strength 15 N/mm (ASTM D624) Solar Reflectance Index 112 (ASTM E1980) Water absorption < 20 % (ASTM D570) Water vapour transmission ~23 g/m224h (ASTM E96) Chloride ion diffusion resistance Very low (ASTM C1202) Microbiological resistance No growth (ASTM D5590) Behaviour after Artificial Weathering No crack, No blisters, No change of gloss, 500 h (ASTM D4587) SYSTEM INFORMATION System structure Layer Product Primer Sikalastic-10 Primer W Base coat Sikalastic-520 Cool Coat Fibers IN Top coat Sikalastic-520 Cool Coat Fibers IN (Optional) Clear coat Sikalastic-10 Primer W Important: Do not overcoat Sikalastic-520 Cool Coat Fibers IN with tile, concrete or others. Sikalastic-520 Cool Coat Fibers IN is an exposed system. Important: For larger application areas and high demanding applications, use a glass fabric reinforcement Sika Fabric-50 between the coats. For normal exposures, usage of Sika Fabric-50 is optional. Reinforcement (partial or total) must be used over dynamic cracks and joints. Important: For enhanced dirt pick up resistance and easy cleanability, above build up must be further coated with a thin layer of Sikalastic-10 Primer W
